IBR Approved Flanges Suppliers & Stockists in Chennai

IBR Approved Flanges Suppliers & Stockists in Chennai – Riddhi Siddhi Metal Impex

Riddhi Siddhi Metal Impex is one of the leading IBR Approved Flanges suppliers & stockists in Chennai. These Flanges have been designed under national and international industry rules using high-grade raw materials and advanced technology. Our Stainless Steel IBR Approved Flanges in Chennai up to Class 2500, and other products are subjected to various quality checks, and then goes for packaging. IBR Flanges as per international standard ASTM, ASME, API, AISI, BS, ANSI, DIN, JIS, MSSP, and NACE. Advanced Fittings manufactures IBR Flanges in Carbon Steel ASTM A105 Gr. F42, Carbon Steel ASTM A105 Gr. F46, Carbon Steel ASTM A105 Gr. F52, Carbon Steel ASTM A105 Gr. F56, Carbon Steel ASTM A105 Gr. F60, Carbon Steel ASTM A105 Gr. F65, and Carbon Steel ASTM A105 Gr. F70. Moreover, IBR Approved Stainless Steel Flanges can be tailored per our client’s requirements.

IBR Approved Stainless Steel Flanges Supplier, IBR Approved Carbon Steel Flanges Dealer, IBR Approved Flanges Stockist in Chennai.

IBR Approved Stainless Steel Flanges are machined with solid forgings. We are also known as one of the Largest Suppliers of high-quality IBR Approved Stainless Steel Blind Flanges, IBR Pipe Reducing Flange, and many more. IBR Approved Stainless Steel Flanges are defined as one of the essential parts of the Pipe Fitting Industry. We are also known as one of the Largest Suppliers of Stainless Steel Reducer Expander.

IBR Approved Flanges Specification, Grades, Size, & Materials

Specification:	ASME B16.5 IBR Flange
UNI	6Bar 10Bar 16Bar 25Bar 40Bar
Coating	Oil Black Paint, Cold and Hot Dip Galvanized, Anti-rust Paint, Zinc Plated, Yellow Transparent
Test Certificates	EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third-Party Inspection Report, etc
Size Chart	1/2″ to 48″
Most common types of Flange	Forged / Threaded / Screwed / Plate
Pressure Rating ANSI	Class 150 LBS, 900 LBS, 2500 LBS, 1500 LBS, 300 LBS, 600 LBS
JIS	5K, 10 K, 16 K 20 K, 30 K, 40 K, 63 K
Standards	BS, ISO 70051, DIN, BS 10, B16.47 Series A & B, API 605, API 6A, EN, ASME B16.47A/B, DIN, EN 1092-1, BS 1042, API7S-43, ASME B16.36, EN-1092, BS1560-3.1, API7S-15, B16.48, ASME/ANSI B16.5, MSS SP44, BS 4504, JIS B2220, GOST, API 590
Connect Type/ Flange Face Type	Large Tongue & Groove, Lap-Joint Face (LJF), Small Male-Female (SMF), Flat Face (FF), Raised Face (RF), Small Tongue, Ring Type Joint (RTJ), Large Male-Female (LMF), Groove
Production technique	Forged, Heat-treated, and machined
EN	10Bar 16Bar 6Bar 25Bar 40Bar

IBR Approved Flanges and Suppliers in Chennai- Riddhi Siddhi Metal Impex

IBR Approved Flange’s dependability and performance have created Riddhi Siddhi Metal Impex leading suppliers, dealers, manufacturers, and exporters of Stainless Steel IBR Approved Flanges in Chennai. Each month we tend to supply/export IBR Approved Flanges to Indian port around fifty-two containers to completely different customers. We are IBR Approved Flanges Supplier in Mumbai, Chennai, Surat, New Delhi, Bangalore, and more than 80+ other cities.

IBR Approved Flanges Exporters in Chennai- Riddhi Siddhi Metal Impex

Riddhi Siddhi Metal Impex exports IBR Approved Flanges to UAE, European countries, Africa, Asian countries, and other continents. We have shipments going to various countries every month. With the increasing clientele, we export 3 containers of IBR Approved Flanges to new locations and ports Each month. We are India’s leading Types of IBR Approved Flanges and have been leading the market for the past few decades.

EIL Approved Flanges Manufacturer in India	Socket Weld Neck Flanges Manufacturers in India
IBR Approved Flanges Manufacturers in India	Slip On Flange Manufacturers in India
Thermowell Flange Manufacturers in India	Blind Flanges Manufacturers in India
Reducer Expander Manufacturers in India	Screwed/Threaded Flanges Manufacturers in India
Flushing Ring Flange Manufacturers in India	Long Weld Neck Flanges Manufacturers in India
ARAMCO Approved Flange Manufacturers in India	Lap Joint Flanges Manufacturers in India
Weld Neck Flanges Manufacturers in India	Spectacle Blind Flange Manufacturers in India
Ring Type Joint Flange Manufacturers in India

Gaskets Manufacturers in Chennai	Valves Manufacturers in Chennai
Condensate Pot Manufacturers in Chennai	Forged Fittings Manufacturers in Chennai
Tube Fittings Manufacturers in Chennai	Filtration & Purification Manufacturers in Chennai
Fasteners Manufacturers in Chennai	SS Flanges Manufacturers in Chennai
Perforated Sheet Manufacturers in Chennai	Buttweld Fittings Manufacturers in Chennai

CLASS	NPS	IBR Approved SORF Flanges	IBR Approved NPT Flanges	IBR Approved SW Flanges	IBR Approved Loose Flanges	IBR Approved BLRF Flanges	IBR Approved WN Flanges
150#	½	1	1	2	1	2	2
	¾	2	2	2	2	2	2
	1	2	2	2	2	2	3
	1¼	3	3	3	3	3	3
	1½	3	3	3	3	4	4
	2	5	5	5	5	5	6
	2½	8	8	8	8	7	10
	3	9	9	9	9	9	11.5
	3½	11	12	11	11	13	12
	4	13	13	13	13	17	16.5
	5	15	15	15	15	20	21
	6	19	19	19	19	27	26
	8	30	30	30	30	47	42
	10	43	43	43	43	70	54
	12	64	64	64	64	123	88
	14	90	90	90	105	140	114
	16	106	98	98	140	180	140
	18	130	130	130	160	220	165
	20	165	165	165	195	285	197
	22	185	185	185	245	355	225
	24	220	220	220	275	430	268
CLASS	NPS	SORF	NPT Flanges	SW	Loose	BLRF	WN
300#	½	2	2	3	2	2	2
	¾	3	3	3	3	3	3
	1	3	3	3	3	4	4
	1¼	4.5	4.5	4	4.5	6	5
	1½	6.5	6.5	6	6.5	7	7
	2	7	7	7	7	8	9
	2½	10	10	10	10	12	12
	3	13	14	13	14.5	16	18
	3½	17	17	17	17	21	20
	4	23.5	24	22	24	28	26.5
	5	29	31	28	28	37	36
	6	39	39	39	39	50	45
	8	58	58	58	58	81	69
	10	81	81	81	91	124	100
	12	115	115	115	140	185	142
	14	165	165	165	190	250	206
	16	210	220	190	234	315	250
	18	253	280	250	305	414	320
	20	315	325	315	375	515	400
	22	370	370	370	435	640	465
	24	490	490	475	550	800	580
CLASS	NPS	SORF	NPT Flanges	SW	Loose	BLRF	WN
600#	½	2	2	2	2	3	3
	¾	3	3	3	3	4	4
	1	4	4	4	4	4	4
	1¼	5	5	5	5	6	6
	1½	7	7	7	7	8	8
	2	9	9	9	9	10	12
	2½	13	13	13	12	15	18
	3	16	16	16	15	20	23
	3½	21	21	21	20	29	26
	4	37	37	37	36	41	42
	5	63	63	63	63	68	68
	6	80	80	80	78	86	81
	8	115	15	15	112	140	120
	10	177	177	177	195	231	190
	12	215	215	215	240	295	226
	14	259	259	259	290	378	347
	16	366	366	366	400	527	481
	18	476	476	476	469	665	555
	20	612	612	612	604	855	690
	22	590	590	590	670	1000	720
	24	876	876	876	866	1250	977

Standard	Class	No. of Bolts	Bolt Circle Dia.	Bolt Size	Dia.	Dia. of Bolt Hole
AS4087	PN14	4	67	M12	95	14
AS 2129 Flange	Table C	4	67	13	95	14
	Table D	4	67	13	95	14
	Table E	4	67	13	95	14
	Table F	4	67	13	95	14
	Table H	4	83	16	114	17
	Table J	4	83	16	114	17
ANSI B16.5	ANSI 150	4	60	13	89	16
	ANSI 300	4	67	13	95	16
	ANSI 600	4	67	13	95	16
	ANSI 900	4	83	19	121	22
	ANSI 1500	4	83	19	121	22
ISO 7005 (DIN) Flange	PN6	4	55	M10	80	11
	PN10	4	65	M12	95	14
	PN16	4	65	M12	95	14
	PN20	4	60.5	M14	90	16
	PN25	4	65	M12	95	14
	PN40	4	65	M12	95	14
