Dimensions of Flanges Size and Weight Chart Riddhi Siddhi Metal Impex manufactures a large capacity of large width flanges for the most demanding jobs in the vigor and industrial fields. We can produce a wide range of large diameter sizes and shapes, utilizing frequently appropriate construction materials for each application. And because they are Riddhi Siddhi Metal Impex products, you can be certain that you will receive these heavy-duty mechanisms light years ahead of the estimated distribution of other benefactors. Check out the Flange Dimension Chart with Weight right now. Riddhi Siddhi Metal Impex is one of the leading Flanges Manufacturers in Mumbai, India.
ASME/ANSI B16.47 Large Diameter Steel Flanges include NPS 26 through NPS 60. Pressure ratings, temperature ratings, materials, dimensions, tolerances, marking, and testing are all addressed in this standard for flanges of this size with rating classes of 150, 300, 400, 600, and 900.
Check Weight and Dimension Chart Class 150 Flange, Class 300 Flange, Class 600 Flange, Class 900 Flange, Class 1500 Flange, Class 2500 Flange
Class 150 Flange Weight Weight Chart
| NOMINAL SIZE | DIMENSIONS | WEIGHT (KG) | ||||
|---|---|---|---|---|---|---|
| NPS (Inches) |
DN (mm) | FLANGE MM |
FLANGE THICKNESS |
SOW SW |
WN | BLIND |
| 1/2 | 15 | 88.9 | 11.2 | 0.4 | 0.5 | 0.4 |
| 3/4 | 20 | 98.6 | 12.7 | 0.6 | 0.7 | 0.6 |
| 1 | 25 | 108 | 14.2 | 0.8 | 1 | 0.9 |
| 1 1/4 | 32 | 117.3 | 15.7 | 1 | 1.3 | 1.2 |
| 1 1/2 | 40 | 127 | 17.5 | 1.3 | 1.7 | 1.5 |
| 2 | 50 | 152.4 | 19.1 | 2.1 | 2.6 | 2.4 |
| 2 1/2 | 65 | 177.8 | 22.4 | 3.3 | 4.1 | 3.9 |
| 3 | 80 | 190.5 | 23.9 | 3.9 | 4.9 | 4.9 |
| 3 1/2 | 90 | 215.9 | 23.9 | 4.8 | 6.1 | 6.2 |
| 4 | 100 | 228.6 | 23.9 | 5.3 | 6.8 | 7.0 |
| 5 | 125 | 254 | 23.9 | 6.1 | 8.6 | 8.6 |
| 6 | 150 | 279.4 | 25.4 | 7.5 | 10.6 | 11.3 |
| 8 | 200 | 342.9 | 28.4 | 12.1 | 17.6 | 19.6 |
| 10 | 250 | 406.4 | 30.2 | 16.5 | 24 | 28.6 |
| 12 | 300 | 482.6 | 31.8 | 26.2 | 36.5 | 43.2 |
| 14 | 350 | 533.4 | 35.1 | 34.6 | 48.4 | 58.1 |
| 16 | 400 | 596.9 | 36.6 | 44.8 | 60.6 | 76.1 |
| 18 | 450 | 635 | 39.6 | 48.9 | 68.3 | 93.7 |
| 20 | 500 | 698.5 | 42.9 | 61.9 | 84.5 | 122.0 |
| 24 | 600 | 812.8 | 47.8 | 86.9 | 115 | 185.0 |
Class 300 Flanges to ASME B 16.5 Weight Chart
| NOMINAL SIZE | DIMENSIONS | WEIGHT (KG) | ||||
|---|---|---|---|---|---|---|
| NPS (Inches) |
DN (mm) | FLANGE OD A MM |
FLANGE THICKNESS D MM |
SOW SW |
WN | BLIND |
| 1/2 | 15 | 95.3 | 14.2 | 0.6 | 0.8 | 0.6 |
| 3/4 | 20 | 117.3 | 15.7 | 1.1 | 1.3 | 1.1 |
| 1 | 25 | 124 | 17.5 | 1.4 | 1.5 | 1.4 |
| 1 1/4 | 32 | 133.4 | 19.1 | 1.7 | 2.0 | 1.8 |
| 1 1/2 | 40 | 155.5 | 20.6 | 2.5 | 2.9 | 2.7 |
| 2 | 50 | 165.1 | 22.4 | 2.9 | 3.4 | 3.2 |
| 2 1/2 | 65 | 190.5 | 25.4 | 4.3 | 5.2 | 4.9 |
| 3 | 80 | 215.9 | 28.4 | 5.9 | 6.9 | 6.8 |
| 3 1/2 | 90 | 228.6 | 30.2 | 7.3 | 8.7 | 8.7 |
| 4 | 100 | 254 | 31.8 | 9.6 | 11.2 | 11.5 |
| 5 | 125 | 279.4 | 35.1 | 12.3 | 15.1 | 15.6 |
| 6 | 150 | 317.5 | 36.6 | 15.6 | 19.1 | 20.9 |
| 8 | 200 | 381 | 41.1 | 24.2 | 29.9 | 34.3 |
| 10 | 250 | 444.5 | 47.6 | 34.1 | 42.7 | 53.3 |
| 12 | 300 | 520.7 | 50.8 | 49.8 | 61.8 | 78.8 |
| 14 | 350 | 584.2 | 53.8 | 69.9 | 85.8 | 105.0 |
| 16 | 400 | 647.7 | 57.2 | 88.1 | 106.0 | 137.0 |
| 18 | 450 | 711.2 | 60.5 | 109.0 | 131.0 | 175.0 |
| 20 | 500 | 774.7 | 63.5 | 134.0 | 158.0 | 221.0 |
| 24 | 600 | 914.4 | 70.0 | 201.0 | 230.0 | 339.0 |
Class 900 Flanges to ASME B 16.5 Weight Chart
| NOMINAL SIZE | DIMENSIONS | WEIGHT (KG) | ||||
|---|---|---|---|---|---|---|
| NPS (Inches) |
DN (mm) | FLANGE OD A MM |
FLANGE THICKNESS D MM |
SOW SW |
WN | BLIND |
| 1/2 | 15 | 120.7 | 22.4 | 1.8 | 1.9 | 1.8 |
| 3/4 | 20 | 130 | 25.4 | 2.4 | 2.6 | 2.4 |
| 1 | 25 | 149.4 | 28.4 | 3.6 | 3.7 | 3.6 |
| 1 1/4 | 32 | 158.8 | 28.4 | 4 | 4.3 | 4.1 |
| 1 1/2 | 40 | 177.8 | 31.8 | 5.5 | 5.9 | 5.8 |
| 2 | 50 | 215.9 | 38.1 | 10.2 | 10.8 | 10 |
| 2 1/2 | 65 | 244.3 | 41.1 | 13.9 | 15 | 14 |
| 3 | 80 | 241.3 | 38.1 | 11.6 | 13.7 | 13.1 |
| 4 | 100 | 292.1 | 44.5 | 19.7 | 22.5 | 26.9 |
| 5 | 125 | 349.3 | 50.8 | 31.9 | 37.4 | 36.5 |
| 6 | 150 | 381 | 55.6 | 41.1 | 47.7 | 47.4 |
| 8 | 200 | 469.9 | 63.5 | 70.7 | 81.3 | 82.5 |
| 10 | 250 | 546.1 | 69.9 | 101.0 | 119 | 122.0 |
| 12 | 300 | 609.6 | 79.2 | 133.0 | 157.0 | 173.0 |
| 14 | 350 | 641.4 | 85.6 | 153.0 | 180.0 | 206.0 |
| 16 | 400 | 704.9 | 88.9 | 185.0 | 217.0 | 259.0 |
| 18 | 450 | 787.4 | 101.6 | 258.0 | 292.0 | 367.0 |
| 20 | 500 | 857.3 | 108.0 | 317.0 | 362.0 | 463.0 |
| 24 | 600 | 1041.4 | 139.7 | 606.0 | 665.0 | 876.0 |
Class 1500 Flanges to ASME B 16.5 Weight Chart
| NOMINAL SIZE | DIMENSIONS | WEIGHT (KG) | ||||
|---|---|---|---|---|---|---|
| NPS (Inches) |
DN (mm) | FLANGE OD A MM |
FLANGE THICKNESS D MM |
SOW SW |
WN | BLIND |
| 1/2 | 15 | 120.7 | 22.4 | 1.8 | 1.9 | 1.8 |
| 3/4 | 20 | 130 | 25.4 | 2.4 | 2.6 | 2.4 |
| 1 | 25 | 149.4 | 28.4 | 3.6 | 3.7 | 3.6 |
| 1 1/4 | 32 | 158.8 | 28.4 | 4 | 4.3 | 4.1 |
| 1 1/2 | 40 | 177.8 | 31.8 | 5.5 | 5.9 | 5.8 |
| 2 | 50 | 215.9 | 38.1 | 10.2 | 10.8 | 10.1 |
| 2 1/2 | 65 | 244.3 | 41.1 | 13.9 | 15 | 14 |
| 3 | 80 | 266.7 | 47.8 | 19.9 | 19.1 | |
| 4 | 100 | 311.2 | 53.8 | 29.9 | 29.9 | |
| 5 | 125 | 374.7 | 73.2 | 55.4 | 58.4 | |
| 6 | 150 | 393.7 | 82.6 | 68.4 | 71.8 | |
| 8 | 200 | 482.6 | 91.9 | 117 | 122 | |
| 10 | 250 | 584.2 | 108 | 194.0 | 210.0 | |
| 12 | 300 | 673.1 | 124 | 288.0 | 316.0 | |
| 14 | 350 | 749.3 | 133.4 | 380.0 | 420 | |
| 16 | 400 | 825.5 | 146.1 | 485.0 | 558.0 | |
| 18 | 450 | 914.4 | 162.1 | 644.0 | 760.0 | |
| 20 | 500 | 984.3 | 177.8 | 775.0 | 965.0 | |
| 24 | 600 | 1168.4 | 203.2 | 1232.0 | 1558.0 | |
Weight Chart of Class 2500 Flanges to ASME B 16.5
| NOMINAL SIZE | DIMENSIONS | WEIGHT (KG) | |||
|---|---|---|---|---|---|
| NPS (Inches) |
DN (mm) | FLANGE OD A MM |
FLANGE THICKNESS D MM |
WN | BLIND |
| 1/2 | 15 | 133.4 | 30.2 | 3.1 | 3.0 |
| 3/4 | 20 | 139.7 | 31.8 | 3.7 | 3.5 |
| 1 | 25 | 158.8 | 35.1 | 5.2 | 5.0 |
| 1 1/4 | 32 | 184.2 | 38.1 | 7.7 | 7.4 |
| 1 1/2 | 40 | 203.2 | 44.5 | 10.9 | 10.4 |
| 2 | 50 | 235 | 50.8 | 16.2 | 15.6 |
| 2 1/2 | 65 | 266.7 | 57.2 | 23.7 | 22.6 |
| 3 | 80 | 304.8 | 66.5 | 36.2 | 34.8 |
| 4 | 100 | 355.6 | 76.2 | 55.3 | 53.9 |
| 5 | 125 | 419.1 | 91.9 | 92.5 | 90.8 |
| 6 | 150 | 482.6 | 108 | 143.0 | 141 |
| 8 | 200 | 552.5 | 127 | 215.0 | 214 |
| 10 | 250 | 673.1 | 165.1 | 406.0 | 411.0 |
| 12 | 300 | 762 | 184.2 | 572.0 | 592.0 |
Flange Weights by Pressure Class and Size in mm kg
| Pipe Size (inch) | 150 # | 300 # | 600 # | 900 # | 1500 # | 2500 # | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| WN | SO | BLD | WN | SO | BLD | WN | SO | BLD | WN | SO | BLD | WN | SO | BLD | WN | SO | BLD | |
| 1/2″ | 2 | 1 | 1 | 2 | 1 | 1 | 2 | 2 | 2 | SEE 1500 # WEIGHTS | 5 | 4 | 4 | 7 | 7 | 7 | ||
| 3/4″ | 2 | 2 | 2 | 3 | 3 | 3 | 4 | 3 | 3 | SEE 1500 # WEIGHTS | 6 | 5 | 6 | 8 | 8 | 8 | ||
| 1″ | 3 | 2 | 2 | 4 | 3 | 3 | 4 | 4 | 4 | SEE 1500 # WEIGHTS | 9 | 8 | 8 | 12 | 11 | 11 | ||
| 1 1/2″ | 4 | 3 | 3 | 7 | 6 | 6 | 8 | 7 | 8 | SEE 1500 # WEIGHTS | 13 | 12 | 13 | 25 | 22 | 23 | ||
| 2″ | 6 | 5 | 5 | 9 | 7 | 8 | 12 | 9 | 10 | SEE 1500 # WEIGHTS | 25 | 25 | 25 | 42 | 37 | 39 | ||
| 2 1/2″ | 8 | 7 | 7 | 12 | 10 | 12 | 18 | 13 | 15 | SEE 1500 # WEIGHTS | 36 | 36 | 35 | 52 | 55 | 56 | ||
| 3″ | 10 | 8 | 9 | 15 | 13 | 16 | 23 | 16 | 20 | 31 | 26 | 29 | 48 | 48 | 48 | 94 | 83 | 86 |
| 4″ | 15 | 13 | 17 | 25 | 22 | 27 | 42 | 37 | 41 | 53 | 53 | 54 | 73 | 73 | 73 | 145 | 125 | 130 |
| 5″ | 19 | 15 | 20 | 32 | 28 | 35 | 68 | 63 | 68 | 86 | 83 | 87 | 130 | 130 | 140 | 245 | 210 | 225 |
| 6″ | 24 | 19 | 26 | 42 | 39 | 50 | 81 | 80 | 86 | 110 | 110 | 115 | 165 | 165 | 160 | 380 | 325 | 345 |
| 8″ | 39 | 30 | 45 | 67 | 58 | 81 | 120 | 115 | 140 | 175 | 170 | 200 | 275 | 260 | 300 | 580 | 485 | 530 |
| 10″ | 52 | 43 | 70 | 91 | 81 | 124 | 190 | 170 | 230 | 260 | 245 | 290 | 455 | 435 | 510 | 1075 | 930 | 1025 |
| 12″ | 80 | 64 | 110 | 140 | 115 | 185 | 225 | 200 | 295 | 325 | 325 | 415 | 690 | 580 | 690 | 1525 | 1100 | 1300 |
| 14″ | 110 | 90 | 140 | 180 | 165 | 250 | 280 | 230 | 355 | 400 | 400 | 520 | 940 | NA | 975 | NA | NA | NA |
| 16″ | 140 | 98 | 180 | 250 | 190 | 295 | 390 | 330 | 495 | 495 | 425 | 600 | 1250 | NA | 1300 | NA | NA | NA |
| 18″ | 150 | 130 | 220 | 320 | 250 | 395 | 475 | 400 | 630 | 680 | 600 | 850 | 1625 | NA | 1750 | NA | NA | NA |
| 20″ | 180 | 165 | 285 | 400 | 315 | 505 | 590 | 510 | 810 | 830 | 730 | 1075 | 2050 | NA | 2225 | NA | NA | NA |
| 22″ | 225 | 185 | 355 | 465 | 370 | 640 | 720 | 590 | 1000 | NA | NA | NA | NA | NA | NA | NA | NA | NA |
| 24″ | 260 | 220 | 430 | 580 | 475 | 790 | 830 | 730 | 1250 | 1500 | 1400 | 2025 | 3325 | NA | 3625 | NA | NA | NA |
Class 600 Flanges to ASME B 16.5 Weight Chart
| NOMINAL SIZE | DIMENSIONS | WEIGHT (KG) | ||||
|---|---|---|---|---|---|---|
| NPS (Inches) |
DN (mm) | FLANGE OD A MM |
FLANGE THICKNESS D MM |
SOW SW |
WN | BLIND |
| 1/2 | 15 | 95.3 | 14.2 | 0.7 | 0.9 | 0.8 |
| 3/4 | 20 | 117.3 | 15.7 | 1.3 | 1.5 | 1.3 |
| 1 | 25 | 124.0 | 17.5 | 1.5 | 1.8 | 1.6 |
| 1 1/4 | 32 | 133.4 | 20.6 | 2 | 2.5 | 2.2 |
| 1 1/2 | 40 | 155.4 | 22.4 | 3 | 3.5 | 3.3 |
| 2 | 50 | 165.1 | 25.4 | 3.6 | 4.4 | 4.2 |
| 2 1/2 | 65 | 190.5 | 28.4 | 5.3 | 6.4 | 6.1 |
| 3 | 80 | 209.6 | 31.8 | 7 | 8.5 | 8.4 |
| 3 1/2 | 90 | 228.6 | 35.1 | 8.8 | 10.7 | 11 |
| 4 | 100 | 273.1 | 38.1 | 14.5 | 17.4 | 17.3 |
| 5 | 125 | 330.2 | 44.5 | 24.4 | 29.2 | 29.4 |
| 6 | 150 | 355.6 | 47.8 | 28.7 | 34.9 | 36.1 |
| 8 | 200 | 419.1 | 55.6 | 43.4 | 53.9 | 58.9 |
| 10 | 250 | 508 | 63.5 | 70.3 | 86.5 | 97.5 |
| 12 | 300 | 558.8 | 66.5 | 84.2 | 103.0 | 124 |
| 14 | 350 | 603.3 | 69.9 | 98.7 | 122.0 | 151 |
| 16 | 400 | 685.8 | 76.2 | 142.0 | 170.0 | 214 |
| 18 | 450 | 743 | 82.6 | 173.0 | 204.0 | 272 |
| 20 | 500 | 812.8 | 88.9 | 220.0 | 254.0 | 349.0 |
| 24 | 600 | 939.8 | 101.6 | 312.0 | 358.0 | 533.0 |
Flange Standard Specification
| Dimensions | ANSI B16.5, ANSI B16.47 Series A & B, MSS SP44, ASA, API-605, AWWA, Custom Drawings |
|---|---|
| Size | 1/2" (15 NB) to 48" (1200 NB) |
| Grades | 300, 301, 301L, 303, 304, 304L, 304H, 310, 310S, 310H, 310, 316L, 316H, 321, 321H, 347, 409, 410, 416, 430, 904L |
| Special Grades | LF 1, LF 2, F 51, F91 |
| Class | 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS, DIN Standard ND-6, 10, 16, 25, 40 Etc. |
| DIN | DIN 2527, DIN 2566, DIN 2573, DIN 2576, DIN 2641, DIN 2642, DIN 2655, DIN 2656, DIN 2627, DIN 2628, DIN 2629, DIN 2631, DIN 2632, DIN 2633, DIN 2634, DIN 2635, DIN 2636, DIN 2637, DIN 2638, DIN 2673 |
| BS Standards | BS 4504, BS 1560, BS 10 |
| PN | PN6, PN10, PN16, PN25, PN40 |
| JIS | 5K, 10K, 15K |
| Duplex | 2205, 31803 |
| Super Duplex | F53, F55, F255, 32550 |
| Hastelloy | C276, C22 |
| Monel | 400, K-500 |
| Inconel | 600, 625, 718, 800, 825, 850 |
| Cupro Nickel | 90-10, 70-30, 80-20, 60-40, 75-25 |
